Specs

• Motor: Das-Kit Rear Hub Motor, 500W, 60 Nm
• Battery: Das-Kit Semi-Integrated 624Wh, 48V, 13A; removable for off-bike charging
• Range: 35–90 km (22–56 miles) riding with pedal assist
• Frame: Aluminum 6061, one-size 18.9" (5'5"–6'1")
• Weight: 67 lb (30 kg)
• Gearing: Shimano Acera 3x8
• Brakes: Tektro mechanical disc brakes
• Front suspension: RST Guid-TNL-26" aluminum with suspension
• Tires: CST 26" x 4.0" fat tires
• Display: Das-Kit L7 LCD (bar mounted)
• Assistance: 6 levels of pedal assist (0–6) with thumb throttle
• Charging: 50% in ~3 hours; 100% in ~6 hours; charger: Das Kit 48V 2A
• Weight rating: Maximum rider + bike 275 lb (125 kg)
• Lighting: Front light DH002 (40 Lux); rear light DR009
• Frame integration: Semi-integrated, frame-integrated battery design
• Certification: TÜV UL 2849

Features

• Powerful traction with 60 Nm torque from the 500W rear hub motor supports hills and mixed terrain
• Long-range 624Wh battery enables extended rides; removable for convenient off-bike charging
• Six-level pedal assist plus thumb throttle for customizable power delivery
• Comfort-focused ride with upright ergonomics, ergonomic grips, and a front suspension
• Reliable shifting with a 3x8 Shimano Acera drivetrain
• Mechanical disc brakes provide confident stopping power across conditions
• Fat-tire capability: 26" x 4.0" CST tires for grip on mud, sand, snow, and loose surfaces
• Integrated electronics: Das-Kit L7 display with backlighting and a 5V USB port for devices
• Frame-integrated battery offers a clean look and protected setup; removable for charging
• Front and rear lighting improve visibility and safety while riding
• On-board charging possible with the removable battery

Compatibility

• Wheel/tire compatibility: 26" fat tires (4.0" width) compatible with the front suspension setup
• Frame and fork: Aluminum 6061 frame designed to accept standard fat-bike components
• Headset: Integrated, tapered 1-1/8" to 1-1/2" configuration
• Electrical system: 48V system with integrated Das-Kit electronics
• Maximum rider weight: 275 lb (125 kg)

Physical

• Frame: Aluminum 6061
• One-size frame suitable for riders approximately 5'5"–6'1" (18.9" seat tube)
• Overall weight: 67 lb (30 kg)
• Suspension: Front suspension fork for improved comfort on varied terrain
• Lighting: Front DH002 40 Lux; rear DR009 for visibility
• Tires: CST 26" x 4.0" fat tires
• Brakes: Tektro mechanical discs
• Drivetrain: 3x8 Shimano Acera gearing
• Battery weight: 7.7 lb (3.5 kg)
• Kickstand: Center-mounted adjustable length
• Pedals: 9/16" alloy platform
